Category

Item

Specification Parameter

INPUT

DC Input

DC5521 12-24V/5A, 21.9V 20A

Solar Input

Input Port

Working Voltage

Power Generation (Max)

DC5521

12V~24V

120W

XT60

24V~55V

400W

DC Input

PD100W

AC OUT 110V

AC Output Voltage

3 AC Sockets, AC110V ± 5%

AC Output Power

1200W

AC Output Over-power Protection

Approximately 1300W

AC Output Waveform

Pure Sine Wave

AC Output Peak Power

2400W, Peak duration <50ms

Frequency

50Hz / 60Hz

USB Output Ports

USB1 Output

QC3.0 MAX 18W, 12V/1.5A; SCP Max Output Power: Max 22.5W

USB2 Output

QC3.0 MAX 18W, 12V/1.5A; SCP Max Output Power: Max 22.5W

TYPE-C1 Output

PD/QC3.0 MAX 30W, 12V/2.5A

DC12V Output

DC1 DC2 Output

12V/10A MAX

TYPE-C Output/Input

TYPE-C2

PD100W Two-way (Bidirectional)

Battery Cell

Type

LiFePO4 Battery / 15000mAh

Capacity

60Ah (6S4P)

Power (Energy)

1152WH

Cycle Life

Over 2000 Cycles

Charging Parameters

Input Specification

DC 12-24V/5A, 21.9V 20A MAX 400W

Charging Time

2.5-3 H (0% to 100% automatic cut-off)

Full Charge Voltage

21.9V ± 0.1V (Voltage when battery reaches automatic cut-off)

LCD Display

Status Display

Displays power level, charging, and stop charging status

Information Display

Power percentage and power bar display; DC, AC, Inverter status, Frequency

Power Consumption

Static at Power-On

<10W

Protection Functions

Types

Short circuit, overload, over-temperature, over-voltage, over-current, under-voltage, etc.

Over-Temperature Protection

Over-Temperature Protection

≥85∘C

Over-Temperature Recovery

≤70∘C
